電子計算機、電子儀器設備裝置用電線電纜

Wire and Cable for Computer,Electrical Apparatus, Instrument and Equipment.

多芯屏蔽電子計算機電纜

Multi-core screened computer cable (enterprise standard )



適用范圍 Application

本產品適用于額定電壓 450/750V 及以下或直流 1000V 及以下的配電裝置中，作為電器、儀表、計算機的連接線。

This product applies for connecting wire of electric appliance , apparatus or computer ,used in distribution equipments with rated voltage up to and including A.C. 450/750V or D.C. 1000V.



使用條件 Condition

電纜允許在環境溫度 -40~50 ℃，相對濕度不大于 80% 時作固定敷設或移動使用，電纜線芯工作溫度不高于 70 ℃，在使用過程中電纜應防止高溫直接輻射或接觸。電纜敷設時溫度應不低于 0 ℃。

The cable is approved to operate upon fixed-installation or moveable using in ambient temperature from-40 ℃ to 50 ℃ ,relative humidity not larger than 80% and operating temperature of core not higher than 70 ℃ as well as avoiding direct high – temperature radiation or contact . The temperature shall never less than 0 ℃ when the cable being laid .



推薦允許彎曲半徑：無鎧裝層電纜應不小于電纜外徑的 6 倍；有鎧裝層或屏蔽層結構的電纜應不小于電纜外徑的 12 倍；有屏蔽結構的軟電纜應不小于電纜外徑的 6 倍。

Permissible bending radius: not less than 6 times of overall diameter for unarmored cable ; not less than 12 times of overall diameter for armored or screened cable ; not less than 6 times of overall diameter for screened flexible cable .
